All-in-One Wire Hanger Forming Cutting Threading Welding Machine
This revolutionary all-in-one machine integrates four essential hanger production processes - wire forming, automatic cutting, hook threading, and spot welding - into a single compact system. By eliminating the need for separate machines, it reduces floor space requirements by 60%, lowers equipment investment costs, and streamlines the entire hanger manufacturing workflow from raw wire to finished product.
Key Features
  • 4-in-1 Integration: Forming + Cutting + Threading + Welding in one seamless automated process
  • Space Saving Design: Replaces four separate machines, reducing workshop footprint by up to 60%
  • PLC Synchronized Control: All processes coordinated by a central PLC system for perfect timing and quality
  • Automatic Wire Feeding: Servo-driven wire feeding system with precise length control
  • Quick Changeover: Easy die swapping system for different hanger sizes and shapes
Technical Specifications
Model QK-AIO-4 All-in-One
Integrated Functions Forming, Cutting, Threading, Welding
Motor Power 4.0 KW Total (2.2KW Forming + 0.8KW Welding + 1.0KW Feeding)
Production Capacity 20-25 pcs/min (complete hanger)
Wire Diameter Range 1.5 - 3.5 mm
Welding Type Resistance Spot Welding
Control System PLC with 10-inch Touch Screen HMI
Machine Weight 1,500 kg
Machine Dimension 2800 x 1800 x 1700 mm
Applications
  • Complete production of laundry wire hangers, garment hangers, and custom hook hangers with or without PVC coating
  • Ideal for manufacturers seeking to minimize equipment investment while maximizing production capability
